8MP & 5MP AI Audio Alarm POE IP Camera
Product Overview
Product Name: 8MP & 5MP AI Audio Alarm POE IP Camera
Core Positioning: Professional HD network security camera with intelligent audio alarm and POE support
Design Highlights: Small, elegant, and delicate appearance, tailored for both home and commercial security needs
Material Advantage: Crafted with aluminum alloy and an innovative patented heat dissipation structure, ensuring stable operation under high temperatures
Core Functions
Intelligent Detection & Alarm:
Human Detection: Triggers audio alarm only when humans are detected, avoiding false alarms from objects or animals
Motion Detection: Activates audio alarm for any moving targets
Multiple Alarm Triggers: Also supports shadow alarm, network cable break alarm, and IP address conflict alarm
Audio Capabilities:
Built-in 23mm large loudspeaker for high-volume audio alerts
Built-in microphone enables two-way audio communication
Customizable Alert Voice: Choose from pre-recorded audios or record your own
POE Support: Simplifies installation with Power over Ethernet, no separate power cable needed
Key Features
HD Imaging & Night Vision:
8MP/5MP high resolution for crystal-clear video
HD CS lens with 2.8mm fixed focus and IR-CUT dual optical filters for auto day/night switching
optional warmlight LEDs or IR LEDs, providing 20~25m effective night vision
Advanced Video Technology:
H.265+/H.265/H.264 compression technology for efficient storage and transmission
3D DNR, auto white balance, auto electronic shutter, and auto electronic gain for real color reproduction and high-resolution images
Network & Compatibility:
ONVIF 2.4 protocol and complete SDK pack for easy integration
Supports RTSP/FTP/PPPoE/DHCP/DDNS/NTP/UPnP network protocols
Remote monitoring via WEB, client software, mobile devices (iOS/Android),
Reliability:
Comprehensive lightning protection (power, network, POE) complying with GB/T17626.5 and IEC61000-4-5 standards
Wide working temperature range: -35℃ ~ 60℃, humidity < 95% (no condensation)
Specifications | BY-IP5KAS | BY-IP8KAS |
|---|
Imaging Sensor | MSTAR316DM+GC4653 | MStar328Q+IMX415 |
Scanning Mode | Progressive Scanning | Progressive Scanning |
Illumination | 1.0Lux (Color) / 0.1Lux (B/W) @F1.2 | 1.0Lux (Color) / 0.1Lux (B/W) @F1.2 |
Standard Lens | 2.8mm fixed focus CS lens | 2.8mm fixed focus CS lens |
Day/Night Switch | IR-CUT dual optical filters auto switch | IR-CUT dual optical filters auto switch |
Image Enhancement | 3D-DNR | 3D-DNR |
Night Vision Source | 4pcs AI ColorVu LED | 4pcs AI ColorVu LED |
Effective Night Vision | 20m full-color | 20m full-color |
Video Compression | H.265+/H.265/H.264; dual stream (AVI); 500K~8Mbps adjustable; PAL/NTSC | H.265+/H.265/H.264; dual stream (AVI); 500K~8Mbps adjustable; PAL/NTSC |
Frame Rate | 8MP@30fps, 5MP@25fps, 5~30fps adjustable | 8MP@30fps, 5MP@25fps, 5~30fps adjustable |
Intelligent Alarms | Human body detection, motion detection, shadow alarm, network cable break, IP conflict | Human body detection, motion detection, shadow alarm, network cable break, IP conflict |
Power Input | DC 12V±10% | DC 12V±10% |
Power Consumption | 1W (IR off) / 9.5W (IR on) | 1.1W (IR off) / 9.6W (IR on) |
Operating Environment | -35℃ ~ 60℃, Humidity <95% (non-condensing) | -35℃ ~ 60℃, Humidity <95% (non-condensing) |
Value-Added Features | WEB configuration, OSD, real-time transmission, remote client/mobile monitoring, full SDK pack | WEB configuration, OSD, real-time transmission, remote client/mobile monitoring, full SDK pack |
